Title: Help needed with 3x L9 setup! Post by: Ers900 on March 16, 2025, 12:38:12 AM Hi guys first post here hopefully you can help me. I have 3x L9’s in my fully brick walled basement, they are located in a back room 3mx2m with intake and exhaust shrouds.
Intake shrouds have a filter and I have an AC in that room to keep it cool (generally stays around avrg 24 degrees C). Exhaust shrouds have a duct going through the wall of the mining room into another 5mx15m room (where the entrance door is at the front). I have a 1070m3h rated fan extracting hot air, but not ducted to outside, (main basement entrance door has 75cmx75cm grills) and have an intake fan rated 1500m3h not currently set up but I plan for it to blow air into the 5mx15m room (not into the mining room). The 2 rooms are divided with a wall & door, (door left open). So the front door and the back mining room distance is more than 15m apart. I have had troubles with high rpm fan speeds and overheating causing the machines to fault. Can someone advise me on the correct set up, for example, must the extraction fan be ducted to go outside the front door? Must the intake duct reach the actually mining room? Can I attach a 3 way T piece to the extraction ducts directly onto the exhaust shrouds? I have tried running all 3 with the door open aswell however they fault (runs smoothly with 1). Is the airflow not right, is that what the problem is? I hope I explained myself and haven’t caused any confusion, if so please fire away and I will answer any questions. I will try upload a floor layout plan to make it clearer to understand. Any suggestions on the correct set up will be a life saver for me. Thank you in advance for your contributions. Title: Re: Help needed with 3x L9 setup! Post by: MeGold666 on March 18, 2025, 06:30:24 PM Title: Re: Help needed with 3x L9 setup! Post by: batsonxl on March 26, 2025, 01:32:55 PM Whats tempretures on asics? Any number will help?
Maybe you dont have enough power to handle all 3. No information how power delivery done. Title: Re: Help needed with 3x L9 setup! Post by: Ers900 on April 29, 2025, 07:20:29 PM I have a 230v supply - 100amp panel (UK) - each miner has its own 20amp breaker/fuse with a 16amp commando socket c19 power cable.
Miner intake temps are between 55-58, outlet temps are 76-79. I managed to get 3 of them working, I have an additional fourth one now. When the fourth one is turned one it’s like a random pick out of the 4 as to which one will overheat and go offline. I believe there is not enough airflow coming in. Which fan specs would be satisfactory enough to feed 4x L9’s airflow? For example would a 10” fan (1130m3h) blowing air into the miner room do the job? Thanks |
