The following guide use openwrt image compiled by technobit team for their line of product.



Disclaimer

1. Use same power source that your miner use to avoid problem.
2. Upgrade firmware if critical operation that need more concern. Do it on your own risk.
3. Do not use wifi connection to do the upgrade, use ethernet cable.
4. Do not power off the unit while upgrade the firmware & or close the browser tab.
5. Do not close your browser while the system applying setting after you click save & apply.
6. I am not responsible for any problem cause by the upgrade.
7. Feel free to PM me if you need more information.



Overview







Official Technobit Release Firmware

The following firmware availabe on technobit download page. Please check the site regularly for new update.

01. 0.1.0  with cgminer-3.8.3
02. 0.1.3  with cgminer-3.8.5
03. 0.1.5  with cgminer-3.10.0
04. 0.1.7  with cgminer-3.10.0
05. 0.1.8  with cgminer-3.11.0
06. 0.2.0  with cgminer-3.12.3
07. 0.2.2  with cgminer-4.0.0
08. 0.3.0  with cgminer-4.2.1
09. 0.3.1  with cgminer-4.2.2
10. 0.3.2  with cgminer-4.2.3
11. 0.3.4  with cgminer-4.3.4
12. 0.3.5  with cgminer-4.4.1
13. 0.3.6  with cgminer-4.4.2
14. 0.3.8  with cgminer-4.5.0
15. 0.3.9  with cgminer-4.5.0
16. 0.4.0  with cgminer-4.6.1
17. DICE  with cgminer-4.9.0



In case you want to restore original firmware, download this original firmware from tplink. Do not download other firmware with boot in the file name.
http://www.tp-link.com/Resources/software/TL-MR3020_V1.00_120817.zip

Kindly PM me if some of the link is unreachable. I had the collection on my hard drive


Unofficial Firmware

1. By 2GOOD 0.3beta
    Feature: Wifi enable, Failsafe working



#1

The default ip of TL-MR3020 is 192.168.0.254. So you need to set you PC ip address to prefix 192.168.0.xx.
No need to set gateway.





#2

Connect TL-MR3020 to PC using ethernet cable.
Then type 192.168.0.254 on your web browser, fill the username & password(both is admin).





#3

Go to System Tools - Firmware Upgrade then choose image downloade from technobit. Use factory.bin file
Click upgrade & let the process finish, the unit will auto reboot. Yoa can see the LED off then on again.





#4

The new default ip after upgrade is 192.168.0.99.
Now open new tab & type 192.168.0.99 then login





#5

Now go to System to set timezone, do not enable ntp client. Save & apply.





#6

Go to System - Administration to set password & enable ssh. Save & apply.





#7

Go to Network - Interfaces to set new ip address if you need. Click edit then change the value. Please use static address. Save & apply.







#8

Now you can re access the TL-MR3020 on your new ip address.
Go to Status - Cgminer Configuration to set pool & miner.

All miner setting(voltage, chips, frequency etc) must be fill & can not left blank , Cgminer won't start. Save & apply.





#9

To upgrade / downgrade current firmware to any openwrt image, go to System - Backup / Flash Firmware

Choose keep setting if you want to use same setting like network & cgminer then use sysupgrade.bin.
Do not keep setting if you want to use factory.bin.
Then hit Flash image.., then Proceed

Do not closed your browser until router restart !!!



If you choose to use sysupgrade.bin, after whole process finish & router restart, ssh to the router & run command:

Code:

/usr/bin/fix_rc

This will disable unnecessary process that not needed.


Bonus

To access cgminer screen, you can use ssh client on your PC.




Then fill username as root & use your password




Then type screen -r






To exit screen without killing cgminer, use ctrl a - d
