[GUIDE][TUTORIAL][XMR,ETH,ETN]How To Mod Bios RX470/570/480/580 VEGA Mining 💰

[troubhacker]

Any information to do it without windoz' ?



[1534283664]

1534283664

[dallase]

Any information to do it without windoz' ?



6x vega56 on linux, running ethminer w/ Mesa Clover OCL.   You can get 39-41mh/s depending on your memclock.   Those 6 I have from 1043 to 1083 right now, just testing accept/stale rates to make sure I'm not missing out by running up the clocks.    Total TDP is ~1150.   You can see the hash rates based on memclocks below.

Code:

# clocks
3: 1083Mhz *
7: 1107Mhz *
3: 1083Mhz *
7: 1107Mhz *
3: 1063Mhz *
7: 1107Mhz *
3: 1063Mhz *
7: 1107Mhz *
3: 1043Mhz *
7: 1107Mhz *
3: 1043Mhz *
7: 1107Mhz *

# rates
GPU #0
-----------------------------------------------------------------------------------------
  m  12:43:51|ethminer|  Speed  40.37 Mh/s    gpu/0 40.37  [A590+6:R0+0:F0] Time: 20:59
-----------------------------------------------------------------------------------------
GPU #1
-----------------------------------------------------------------------------------------
  m  12:43:56|ethminer|  Speed  40.29 Mh/s    gpu/0 40.29  [A74+1:R0+0:F0] Time: 02:52
-----------------------------------------------------------------------------------------
GPU #2
-----------------------------------------------------------------------------------------
  m  12:43:55|ethminer|  Speed  40.04 Mh/s    gpu/0 40.04  [A598+5:R0+0:F0] Time: 20:59
-----------------------------------------------------------------------------------------
GPU #3
-----------------------------------------------------------------------------------------
  m  12:43:53|ethminer|  Speed  40.04 Mh/s    gpu/0 40.04  [A570+4:R0+0:F0] Time: 21:01
-----------------------------------------------------------------------------------------
GPU #4
-----------------------------------------------------------------------------------------
  m  12:43:56|ethminer|  Speed  38.80 Mh/s    gpu/0 38.80  [A562+5:R0+0:F0] Time: 21:01
-----------------------------------------------------------------------------------------
GPU #5
-----------------------------------------------------------------------------------------
  m  12:43:53|ethminer|  Speed  39.15 Mh/s    gpu/0 39.15  [A88+1:R0+0:F0] Time: 02:51
-----------------------------------------------------------------------------------------

and wattage @ 875mv cores...

Code:

# gfx
GFX Clocks and Power:
1083 MHz (MCLK)
1107 MHz (SCLK)
1138 MHz (PSTATE_SCLK)
800 MHz (PSTATE_MCLK)
875 mV (VDDGFX)
132.0 W (average GPU)

--
GFX Clocks and Power:
1083 MHz (MCLK)
1107 MHz (SCLK)
1138 MHz (PSTATE_SCLK)
800 MHz (PSTATE_MCLK)
875 mV (VDDGFX)
131.0 W (average GPU)

--
GFX Clocks and Power:
1063 MHz (MCLK)
1107 MHz (SCLK)
1138 MHz (PSTATE_SCLK)
800 MHz (PSTATE_MCLK)
875 mV (VDDGFX)
135.0 W (average GPU)

--
GFX Clocks and Power:
1063 MHz (MCLK)
1107 MHz (SCLK)
1138 MHz (PSTATE_SCLK)
800 MHz (PSTATE_MCLK)
875 mV (VDDGFX)
139.0 W (average GPU)

--
GFX Clocks and Power:
1043 MHz (MCLK)
1107 MHz (SCLK)
1138 MHz (PSTATE_SCLK)
800 MHz (PSTATE_MCLK)
875 mV (VDDGFX)
125.0 W (average GPU)

--
GFX Clocks and Power:
1043 MHz (MCLK)
1107 MHz (SCLK)
1138 MHz (PSTATE_SCLK)
800 MHz (PSTATE_MCLK)
875 mV (VDDGFX)
125.0 W (average GPU)

Running nightly kernel, mesa 18, ethminer 0.15.0-dev, etc etc etc...

[GunsN]

Hello, what is the best bios mod for RX580 8GB V1?
please give me some advice, thank you

[Branko]

Hello, what is the best bios mod for RX580 8GB V1?
please give me some advice, thank you

The best is the one that gives you the best hashrate with least power spent

[Darius1992]

I was wondering since im selling one of my cards.

If my card was bios modded and i revert it to stock, will the other person need to run pixel patcher or anything.

How do i approach this?Kinda worried they might think i sold them a bricked card if something goes wrong.

[Call_Me_Bambi]

I was wondering since im selling one of my cards.

If my card was bios modded and i revert it to stock, will the other person need to run pixel patcher or anything.

How do i approach this?Kinda worried they might think i sold them a bricked card if something goes wrong.

If you restore the original BIOS there will be no need to run pixelpatcher, you can test it by installing original video drivers that will not work with a modded card, then flash the original BIOS and run again. If the card now works in its full resolution (or whatever your monitor can manage) then it's successfully restored to it's original condition.

I have sold cards that I had modded the BIOS on them and before selling I restored the original BIOS and have had no complaints.

[ermis1975]

Hello I have a 570 8gb nitro+ with micron memory. I want to know if the bios in the card is the original one. I mine with 25 now. And the best bios to use to go up to 30-31...! Thanks.

[greatauror28]

Hello I have a 570 8gb nitro+ with micron memory. I want to know if the bios in the card is the original one. I mine with 25 now. And the best bios to use to go up to 30-31...! Thanks.

Use PBE one-click thingy then flash your modded bios - guaranteed >30Mh for Rx580.

[big_daddy]

@dev
I cannot find on Your web the bios for the RX MSI 570 8GB, V341-236R, (Armor)
any hints?

[Mattthev]

@dev
I cannot find on Your web the bios for the RX MSI 570 8GB, V341-236R, (Armor)
any hints?

There aren't all bios there. You can use this guide and mod it or buy PBE 2.2 there.

[DenJohn]

@dev
I cannot find on Your web the bios for the RX MSI 570 8GB, V341-236R, (Armor)
any hints?

Have you checked: https://anorak.tech/search?context=topic&context_id=13&q=Msi%20rx%20570&skip_context=true

[erwnrsty]

I have a Gigabyte RX 580 8G Gaming card and I've tried everything that you have suggested in your FAQ after using PBE 2.2. I'm using Claymore to mine ETH. While I am mining I start MSI Afterburner and all of the settings at the default settings are Core Voltage 0, Power Limit 0, Temp Limit 90, Core Clock 1340, Memory Clock 2000, Fan speed 47, Voltage 1106 mV and Temp is 74. The GPU power draw is 121.4 watts. I'm only getting1 extra Mh/s (around 25.7 instead of stock bios of 24.6 Mh/s). Can you please help me figure out how to increase the hash rate to 29-30 that I am reading about when modding the Bios. I do appreciate your help in this matter.

[BSAlex]

I have a Gigabyte RX 580 8G Gaming card and I've tried everything that you have suggested in your FAQ after using PBE 2.2. I'm using Claymore to mine ETH. While I am mining I start MSI Afterburner and all of the settings at the default settings are Core Voltage 0, Power Limit 0, Temp Limit 90, Core Clock 1340, Memory Clock 2000, Fan speed 47, Voltage 1106 mV and Temp is 74. The GPU power draw is 121.4 watts. I'm only getting1 extra Mh/s (around 25.7 instead of stock bios of 24.6 Mh/s). Can you please help me figure out how to increase the hash rate to 29-30 that I am reading about when modding the Bios. I do appreciate your help in this matter.

Start with the options that will give you lower power consumption.
1. Power Limit -20
2. CC - 1200
3. Do not set fan to fixed, set target temp to 55
4. Set Cvoltage to 950

When you'll get your card in range lower then 60 you can try to find your sweet spot in performance by doing small changes, like lowering voltages by 25 step.

Hope it'll help to start your quest for ultimate performance.

[skablast]

I am looking for a bios for an rx 550 2gb "baffin" for cryptonight.

I tried to modify it, "pimp" the strap , unlocked the shaders but I saw people able to use it at higher speed and less power than what I did and I'm curios

its not available to purchase anywhere so I'm asking here

[PaRaN0iDnl]

Did anyone get his 6xRX580 mining rig under 850 Watts from the wall using SMOS ?

I am struggling. people tried to help, but it seems i cant get gpu vddc below 950mv , and per card its pulling about 150 watts.  Is this still the problem using Linux/SMOS ?

3x sapphire nitro+    8 gb  Micron
1x sapphire nitro+    8 gb  Hynix
2x Gigabyte Gaming 4 gb  Samsing

Note that i only tried to change the mV value of the GPU en MEMORY using polaris master, i've set them to 850 , but still it seems it wont go lower that 950.   Have not tried power play or something like that.

Could that be the thing why it wont go lower? Or is this just still the problem of Linux and SMOS?

[ermis1975]

I have a 570 8gb nitro + card. After bios moding how much energy must consume ? I calculate 150-160 watts.

[frame3]

Has anyone tried http://bios.rigswitch.com

[samches]

Can someone PLEASE share modded bios for

XFX RX480 GTR 8GB (samsung)

I cant get it working... my best result is ~28mh/s on ETH and when I try to overclock the memory over 2000, system crashes.

Please HELP!

[otto_diesel]

Hi,

i bought a Asus rog strix rx470  (hynix rom) on mathews web site, and its works fine,

but there is no for Rx470 (elpida)  for same card?

do any one have  these rom ? i  can pay for it, can you help me for this issue



note: anorach rom gives,  gpu fault detected 147 error

[frame3]

Hi,

i bought a Asus rog strix rx470  (hynix rom) on mathews web site, and its works fine,

but there is no for Rx470 (elpida)  for same card?

do any one have  these rom ? i  can pay for it, can you help me for this issue



note: anorach rom gives,  gpu fault detected 147 error

Save your original bios with atiflash and upload it into bios.rigswitch.com to get a modified bios. Just play a bit with memory and core clock settings

For start you can use these settings:
Strap timings: 1500
Core clock: 1150 MHz
Mem clock: 2050 MHz

Note: you don’t have to set voltage, it will use the default values
